press-fitting machine
summary
press-fitting machine is used for assembly of small size disc and rim. it can press disc into rim precisely and can manually adjust offset distance between disc and rim. it also can locate accurately, which can guarantee disc and rims run-out after welding. the whole equipment adopts four-pillar structure, which can guarantee the machine body to keep its rigidity during assembly and can provide their concentricity.
the press-fitting machine is composed of pre-pressing cylinder, pull rod, sliding block, base seat, main oil cylinder and necessary molds.
specification
model number
номер модели
ypj-400-ah
power supply
мощность
ac 380v±10%, 3phase, 50hz
press-fitting force
сила сжатия при сборке
320kn
pressure of compressed air
давление сжатого воздуха
0.4 ~ 0.6mpa
travel of working table
ход рабочего стола
300mm
processing range of rim
диапазон размеров обода
12 inches ~ 18 inches
working table size
размер рабочего стола
900mm x 900mm
