combined welder machine
the 4 torch combined welder machine is an inner ring carbon dioxide gas protection automatic welding machine, it can weld wheel disc and rim automatically. it has a series of advantages such as energy saving, high efficiency, small deformation, high welding strength.
combined welder machine-九游会登录
四头内环缝二氧化碳气体保护自动焊机是汽车车轮轮辐与轮辋合成焊接的专用设备。它具有节能、效率高、变形小、焊接强度高、四段焊缝一次成型等一系列优点。
the 4 torch combined welder machine is an inner ring carbon dioxide gas protection automatic welding machine, it can weld wheel disc and rim automatically. it has a series of advantages such as energy saving, high efficiency, small deformation, high welding strength.
model number
hchj-4x350-ah
working voltage
380v±10%, 3phase, 50hz
adjustable range of turntable speed
0.1 rpm ~ 2 rpm
motor torque
3.8n.m
compressed air pressure
0.4~0.6mpa
axial adjustment of welding torch
100mm
radial adjustment of welding torch
160mm
angle range of welding torch
30-45°
adjusting range of welding voltage
0~30v
adjusting range of welding current
0~500a
welding wire diameter
φ1.2~φ1.6mm
co2 consumption
nominal 15l/minx4, can be adjusted in line with rim specs
